MUTARS® RS ES

proximal (metaphyseal) components

The MUTARS® RS system offers four titanium alloy (TiAl6V4) proximal component options each with a 12/14 morse taper (i.e. 32mm long with a CCD angle of 127°, 42mm long with a CCD angle of 127°, 32mm long with a CCD angle of 135° and finally 42mm long with a CCD angle of 135°). Additionally, there are two lengths (i.e. 40mm or 50mm) of flared TiAl6V4 metaphyseal component as well as up to three 25mm cylindrical TiAl6V4 extension pieces.

All of these hydroxyapatite (HA) coated cementless modular proximal options allow for the optimal choice and position of the actual distal diaphyseal stem to be defined first. Then by putting the proximal component combinations to the best possible use it is possible to restore the leg length, offset and version onto the distal stem.
